Pneumatic Marine Fender Wear-Resistant To High Pressure

Short Description:

Introducing our high-performing Pneumatic Marine Fender, expertly designed to withstand high pressure and provide your vessel with unbeatable protection. Our fender boasts exceptional wear resistance, preventing costly damage to your boat in harsh marine environments. Constructed with premium materials, our fender is built to last, ensuring long-lasting durability and reliable performance. It’s the perfect solution for mitigating the risks of collisions and damage while keeping your boat looking its best. Trust in our Pneumatic Marine Fender to provide you with the ultimate peace of mind while docking.

Send email to us

Product Detail

Product Tags

Common dimensions and properties of Pneumatic Marine fender

SIZE		Initial pressure is 80 kPa Compression deformation 60%
Diameter（mm）	Length (mm)	Reactionforce-kn	Energyabsorb kn-m
500	1000	87	9
600	1000	100	10
700	1500	182	28
1000	1500	241	40
1000	2000	340	54
1200	2000	392	69
1350	2500	563	100
1500	3000	763	174
1700	3000	842	192
2000	3500	1152	334
2000	4000	1591	386
2500	4000	1817	700
2500	5500	2655	882
3000	5000	2715	1080
3000	6000	3107	1311
3300	4500	2478	1642
3300	6000	3654	2340
3300	6500	3963	2534

Inflatable rubber fender, pneumatic rubber fender, Marine fender is popular in today's international ship fender products, using compressed air as buffer medium, make the ship when it is on the list has more soft wall effect, has big impact energy absorption, covers an area of low pressure acting on the ship, high impact fatigue performance, easy to install, etc; Widely used in large oil tanker, liquefied gas ship, chemical ship, offshore platform, large dock, sea, etc.; Qqingdao Jiexing ship fender products are reliable.

Structure diagram of inflatable fender

product-description1

Inflatable rubber fender is a new type of winding fender, abrasion resistance, scratch resistance, resistance to ageing, stung, etc, the appearance of the most prominent feature is the surface of the pneumatic rubber fender ontology by a tire chain net type sheathed packages, protect the fender of ontology is stung by sharp objects, scratches, drop and so on, which is a fender ontology use fixed number of year.
